Name: Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: Wnk80ma
Price: 21.00 USD
Availability: InStock

বাড়ি > পণ্য > Compact Pressure Sensor >

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input

electronic pressure sensor

precision pressure sensor

Compact Pressure Transmitter 100Kpa

উৎপত্তি স্থল:

হেফেই, চীন

পরিচিতিমুলক নাম:

WNK

সাক্ষ্যদান:

CE, SGS, ISO9001

মডেল নম্বার:

Wnk80ma

আমাদের সাথে যোগাযোগ করুন

একটি উদ্ধৃতি অনুরোধ করুন

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input

Product Details

ইনপুট:

-100Kpa - 70Mpa

ডিজিটাল আউটপুট:

I2C, SPI

অ্যানালগ আউটপুট:

4-20mA, 0.5-4.5VDC

চাপ সংযোগকারী:

NPT1/8 G1/4 কাস্টমাইজড

রৈখিক নির্ভুলতা:

0.5% FS, 1.0% FS

চাপ ওভারলোড:

2-3 বার

প্রমাণ:

IP67

বিশেষভাবে তুলে ধরা:

electronic pressure sensor

precision pressure sensor

Compact Pressure Transmitter 100Kpa

Payment & Shipping Terms

ন্যূনতম চাহিদার পরিমাণ

5 টুকরা

মূল্য

negotiable

প্যাকেজিং বিবরণ

সমুদ্র-যোগ্য প্যাকিং বা বায়ু-যোগ্য প্যাকিং

ডেলিভারি সময়

7-10 কার্যদিবস

পরিশোধের শর্ত

টি/টি, ওয়েস্টার্ন ইউনিয়ন, মানিগ্রাম

যোগানের ক্ষমতা

প্রতি মাসে 5000 পিসি

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

সেরা দাম পান

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

সেরা দাম পান

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

সেরা দাম পান

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

সেরা দাম পান

আমাদের সাথে যোগাযোগ করুন

এখনই যোগাযোগ করুন

Product Description

Digital Hydraulic Water Treatment Compact Pressure Sensor Pressure Transmitter

Description

WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. In addtion to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement

Specifications

Applicable media	Liquid, Gas
Pressure range	0-7kPa~350bar
Pressure measurment	Gauge Pressure, Absolute pressure, Sealing pressure
Output	4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical)
Power supply	24VDC/12VDC/5VDC/3.3V
Compensation temperature	-20~85ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel(inner core is 316 stainless steel)
Protection	IP65

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input 0

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input 1
